Product Description

Function: Transmits data from a central controller rack to an expansion rack. Module Pair: Operates paired with the IM 461-1 receive module (6ES7461-1BA01-0AA0). Link Range: Built for local connections spanning a cumulative length of up to 1.5 metres. Power Handling: Facilitates a central coupling connection with Power Supply (PS) transfer but operates without a Communication (C) bus. Power Attributes: Consumes an electrical input current of 85 mA and features a power loss of 425 mW. Siemens +3 System Installation Rules Expansion Limits: Only one expansion rack can be connected per interface line. Power Supply Restriction: Separate power supply modules are not permitted in the connected expansion rack. Current Capacities: Total current requirements for modules hosted in the connected expansion rack must not exceed 5 V / 5 A. Ungrounded Operation: Connecting via local link with 5 V transmission mandates ungrounded operation for the expansion rack
