Product Description

FX3U: The 3rd generation high-speed, expandable compact PLC series from Mitsubishi Electric. 32: Total number of fixed digital I/O points (16 inputs and 16 outputs). M: Main unit CPU base block. T: Transistor output type (essential for high-speed pulse applications like servo/stepper control). ES: Standard classification indicating AC power supply, sink/source type DC inputs, and sink type transistor outputs. MITSUBISHI ELECTRIC UNITED KINGDOM +4 Core Technical Specifications Official specifications provided via the Mitsubishi Electric Product Catalogue include: Mitsubishi Electric e-shop Power Supply: 100V AC to 240V AC (50/60 Hz) wide-range compatibility. Digital Inputs: 16 channels, 24V DC bidirectional (can be wired as either sink or source). Digital Outputs: 16 channels, Transistor types with Sink configuration. High-Speed Counter: Integrated inputs supporting up to 100 kHz. Positioning Pulse Outputs: Integrated independent multi-axis pulse train outputs supporting up to 100 kHz for motion control. Programming Software: Configured and programmed via GX Works2 or GX Developer using ladder logic. Mounting Type: Integrated 35mm DIN rail mounting compatibility. MITSUBISHI ELECTRIC UNITED KINGDOM +6 Applications Due to its rapid internal processing speeds and dedicated high-speed transistor outputs, this unit is frequently deployed in machine automation setups requiring precise positioning, such as: IndiaMART +1 Conveyor tracking and packaging machines. Material handling and assembly line sorting. Multi-axis servo/stepper motor coordination.
